시각화 플랫폼 디스플레이 군용 모니터 UTL-19A 19 inch Rugged LCD(UTL-19A) 구매수량 회원가 로그인하세요. 장바구니 바로구매 견적문의 첨부파일 다운로드 Specification UTL-19A.pdf 확장자 : pdf 파일크기 : 4.74MB 다운로드 19 INCH Millitary Standard Monitor MIL-STD-810F MIL-STD-167 MIL-STD-461/462D Model No. UTL-19A Product Name 19" Monitor Physical Weight Below 12 Kg Dimension 482 x 399 x 100 mm Bolt Lock 465 x 324 Power Supply AC 110~230 V DC 24V Power Consumption Below 100 Watt Reference Required NAVY Vessel Electro-Optical Panel Size 19 inch Brightness 200 cd/M2 (EMI Protect) Resolution 1600 X 1200 Contrast Ratio 300 :1 (Dark Enviroment) Emviroment Temperature MIL-STD-810F Operating: -10℃ ~ +55℃ Storage : -32℃ ~ +63℃ Humidity MIL-STD-810F Vibration MIL-STD-167 type 1 Shock MIL-STD-810F EMC/EMI MIL-STD-461/462D CE,CS,RE,RS Input Signal BNC 3 Pin / BNC 5 Pin BNC 8 Pin / D-SUB Power Connector 1. MS85049/49-214N(DC) 2. MS27466 Options Secured Video Encoding H.264 or H.264HP Encoding Port 1 x IP Port (100M) Secured Video Recording NSE (External Connection) Secured Vessel Black Box
