시각화 플랫폼 디스플레이 키오스크

KIOSK ULW65-OD

KIOSK (Outdoor)

구매수량
회원가
로그인하세요.

> Industrial Stand Case Design with SGCC Galvanized Steel Plate with Internal Surface

Zinc Powder and External Surface with Dupont Outdoor Plastic Powder for over 10 Years Lifespan.

> Modalized Design for Flexible & Continuous Maintenance.

> Waterproof, Dustproof, Anti-sunshine, Anti-corrosion, Ultraviolet Resistance, Anti- theft,

Anti-Moisture , Anti-thunder, Electric Leakage Protection.

> Full HD LCD Panel with High Brightness(2000Nit) and Intelligent Brightness Adjustment.

> Air Condition(IP65) Heating Dispassion

> Time Switcher, Shockproof ,Military Quality Grade Power Supply.

> Windows Operating System

> 6mm AR Anti-Glare Laminated Tempered Glass with 97% Light Transmittance and Reectivity 3%.

> Support Hardware Appearance & Module Customization.


65inch Waterproof Outdoor KIOSK_ULW65-OD
Diagonal Size 65 inch
Resolution  1080 x1920
Display Area 1428.3mm x 803.5mm
LCD Panel LG Industrial A Grade Panel
Viewing Angle 178 °（H）/ 178 °（V）
Response Time 5ms
Display Ratio 16:09
Contrast Radio 3500:01:00
Brightness  2000cd/㎡(adjustable)
Lifespan ≥ 60000 Hours
Brightness Adjust auto light brightness adjustment
Display Area 1428mm x 803mm
Touch Screen Type Nano Touch  Interactive Screen
6mm laminated glass  Fully tempered glass with AR anti-glare,
Light transmittance≥97%,
solar isolation rate≥52%, reflection rate ≤3%
Industrial Air Conditioner
Input Voltage of Compressor AC220V/50Hz
Refrigerating Fluid R134a
Refrigerating Capacity L35℃ 1000W
Working Temperature Range -35℃ ~ +55℃
Noise Grade   ＜65 dB
Internal CFM ＞200
External CFM ＞330
Protection Grade IP65
Lifespan  50000H
MTBF 40000H
Built-In PC
Chipset Group Intel H81
Mainboard Industrial MINI-ITX 170mm x 170mm
CPU Core I7
Graphics Card Intel HD Graphics
Storage DDR3 4G + 128G SSD
Interface 4* USB 2.0, 1*HDMI output, 1* VGA/DVI output, MIC *1,
Ethernet Network 10/100/1000M self-adapaive network card
WIFI 802.1b/g/n WIFI (option)
Operating System Windows System
General
Louder Speaker 2x 8W
Power Supply AC110V~240V
Power Consumption ≤780W standby ≤3W
Working Temperature -35℃～55℃
Working Humidity 10%～90%
Storage Temperature -35℃～60℃
Storage Humidity 10%～90%
Professional Enclosure Industrial Stand Case Design with SGCC Galvanized Steel Plate with Internal Surface  Zinc Powder and External Surface with Dupont Outdoor Plastic Powder
Other
Structure Enclosure Waterproof, Dustproof, Anti-sunshine, Anti-corrosion, Ultraviolet Resistance,
Anti- theft, Anti-Moisture
            Test System Spray water-proof testing, Temperature Environmental testing, Solar Radiation testing,
pre-delivery aging test
Electric Control System Leakage-proof and Over-voltage protection
Timer Switch(Time-Interval control start and stop)
Shockproof(C grade Shockproof preventing instant lightning strike )
Military quality power supply( Stable and reliable)
