Excellent Image Quality
· All modules use 1/1.8’’ CMOS sensors
· High-definition panoramic and close-up imaging
· Panorama: Dual 400W fixed-focus lenses with 190° stitching, output resolution 5120×1440
· Close-up: 400W lens, resolution 2688×1520
· Simultaneous output of 1 panoramic video and 1 close-up video
· Enhanced image brightness, contrast, and quality in face and plate regions
Smart Tracking and Recognition
· Synchronized panorama-close-up linkage for detection, tracking, and snapshot
· Detects and classifies humans, motor vehicles, and non-motorized vehicles
· PTZ linkage enables close-up tracking from panoramic detection
· Captures 7 image types:
1) Face close-up 2) Full-body 3) Vehicle 4) License plate
5) Non-motorized vehicle 6) Scene panorama 7) Compressed panorama
· Attribute analysis for:
- People: gender, age, glasses, mask, clothing color & style
- Vehicles: plate number, plate color, type, body color, brand & sub-brand
· Supports face and license plate watchlists (≥150,000 image capacity)
Event Detection and Counting
· Real-time classification and counting of pedestrians, motor and non-motor vehicles
· Detects:
- Illegal parking - Wrong-way driving
- Lane line crossing - Non-motorized lane occupation
Audio and Communication
· Converts custom text (via web interface) into audio playback
· Supports ≥1 audio input and ≥1 audio output
Environmental Adaptability
· Front lens cover heating for de-icing and de-fogging
· IP66 protection level
· Operating temperature: -40°C ~ 70°C
· Operating humidity: ≤ 95%
Connectivity and Compatibility
· Supports ONVIF, RTSP, HTTP, HTTPS protocols
