UMK5138

영상보안 기타 키보드

네트워크 키보드 컨트롤러

⋅10.1 inch capacitive touch screen, support multi-touch.

⋅its high definition decoding SOC chip to provide efficient encoding and decoding capabilities.

⋅Hall type 4-D joystick for precise PTZ control and snapshot.

⋅Support 1ch HDMI output, with maximum 4K@60Hz resolution.

⋅Support camera direct control, matrix control, platform control and other control methods;

⋅Support H.264, H.265 video stream decoding, support up to 16 window segmentation display.

Model	UMK5138
Specification
Touch Screen	10.1", resolution 1280 * 800，backlight is adjustable
HDMI	1，maximum 4K@60Hz and backward compatible
Audio	support HDMI embedded output support standard 3.5MM audio socket, input and output dual audio.
Decoding format	compatible H.264、H.265 encoding support G711A,G711U,AAC audio encoding
Decoding capability	maximum 8ch 1080p@30fps can decode 1ch 8MP or 10MP or 12MP
Access	support Onvif, RTSP
Control mode	support direct control to network camera, Matrix control and platform or VMS control.
Network camera control	PTZ control, preset read back, set and call.
Video wall control	splicing, segmentation, plan, macro switching, image switching, etc.;
Serial port	1 RS-485，speed rate can set. 1 RS-232，speed rate can set.
Network port	1 RJ45，1000M self-adaptive ethernet.
USB	2*USB2.0，support mouse, keypad, U flash.
Storage temperature	-40℃ ～ 60℃
Working temperature	-10℃ ～ 45℃
working humidity	10% ～ 90%（non-condensing）
Voltage	standard 5.5/2.1 power socket，DC12V/2A；
Power	＜18W
Net gross	1.9KG
Product size	358(L)×173(W)×127(H)mm
Inner box size	435(L)×295(W)×185(H)mm
Certifucate	CE
