UBT-CSP930

SIP Waterproof Column Speaker

회원가
로그인하세요.

Audio characteristics

⋅ Narrowband speech coding: G.711a/u, G.723.1, G.726-32K, G.729AB;

⋅ Wideband speech coding: G.722

⋅ Voice Activation Detection I Silence Suppression;

Network characteristics

⋅ Support SIP 2.0, TCP/IP, UDP, DHCP;

⋅ Support primary DNS and secondary DNS servers;

⋅ Support VLAN;

⋅ Support SNTP client;

⋅ Support VPN L2TP/PPTP;

⋅ Support SRTP;

⋅ Support web page HTTP/HTTPS;

⋅ Support QoS: 802.1 p/q, DSCP;

⋅ Support MDS authentication;

⋅ DHCP /static/ PPPoE;

⋅ STUN;

Configuration and management

⋅ Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR069;

⋅ Web management interface;

⋅ Web page packet capture (Web-based Packet-dump);

⋅ Config export/import;

⋅ Software upgrade;

⋅ System work log (Syslog);

Model  UBT-CSP930
Communication interface Rj45
Line output 1000mV
Communication protocol TCP/IP,UDP,DHCP,SIP
Line input 500mV
SIN ratio ⩾97dB
Dimensions(W * D* H) 493 x 152 x 100mm
Net weight 3.28Kg
Maximun current 600mA
PSE AC220V/DC12-24V
Output audio response 40-16KHz
Network play time ⩽50ms
Network point wake-up time ⩽1 S
Distotion (T.H.D.) THD⩽1%
Repeat inte1Val time ⩽50ms
Real-time play wake-up time ⩽150ms
Model of POE standard IEEE802.3at(POE plus)
Dissipation 20mW
